Aug 04, 2017 XProtect® VMS 2017 R2: Basic features in the Management Client This video tutorial shows you the most basic features you need to know about to administer you XProtect system from the Management. Milestone XProtect® Smart Client 2014 User's Manual www.milestonesys.com Contents The right-click menu.70. XProtect Smart Client is available in 30 languages, allowing users to work with the application in their native language. Using the Milestone Integration Platform and the unique application plug-in architecture, various types of security and business systems applications can be seamlessly integrated in XProtect Smart Client.

About

Founded in 1998, Milestone Systems is a global industry leader in open platform IP video management software. The XProtect platform delivers powerful surveillance that is easy to manage, reliable and proven in thousands of customer installations around the world. With support for the widest choice in network hardware and integration with other systems, XProtect provides best-in-class solutions to video enable organizations – managing risks, protecting people and assets, optimizing processes and reducing costs. Milestone software is sold through authorized and certified partners.

Version 2016

Tested Functions

Version VMS	Version Helios IP	Scan device	Video from HIP	Audio from HIP	Audio to HIP	Switch control	Events from HIP
Milestone XProtect Enterprise 10.0a	2N Helios IP 2.19.0.28.5
Milestone XProtect Enterprise 10.0a	2N Helios IP 2.17.0.26.1
Milestone XProtect Enterprise 10.0a	2N Helios IP 2.14.2.23.4

2N Helios IP Settings

As a very first step you have to do a configuration under the section Onvif. Please keep in mind that the Onvif protocol is licensed, for full functionality you need to have a 'enhanced video' license for 2N Helios IP unit. Enable at least one ONVIF user with the Administrator access level in menu Services / Onvif.

Enable parameter RTSP Server Enabled in menu Services / Streaming

Tested Features

On the side of Milestone server do right click on Hardware Devices and and click on Add New Hardware Device.

In next step you can choose if you want to add device manually or if you want to scan your local network for ONVIF ready devices. We choosed automatic scan as it is much eaiser. Here you can choose if you want to scan local network, or you can define IP range which you want to scan and press next. Then you will see window where you can choose particular manufacturer or it is ok to leave it as it is 'All manufacturers' and click on next. Once the scan will be finished, you will see devices in your network. Find your device and enter valid credentials (we used ONVIF/ONVIF for this FAQ) and press Go. After you will enter valid credentials, it will be possible to pick tde device and click on next. Then you will get a message that device was sucesfully added. No special settings required. Intercom type is recognized automatically.

Now the device will appear in tree menu of 'Hardware Devices'. If you open it, you will see peripheries of the device. If you click on of them, you can change its name. By right clicking on any of them, you can open its Properties and adjust some settings. No special settings required.

No special settings required. Chose the appropriate microphone in the Audio section.

No special settings required. Chose the appropriate speaker in the Audio section.

Alternatively you can configure Talk to speaker button. Enable Setup and configure Overlay Buttons / Application / Talk to speaker(s). Press the button Talk to speaker(s) to stream audio from microphone to the speaker.

Once you have successfully added new hardware devices into the Milestone VMS system (camera, microphone and speaker) which was described in the previous part of this FAQ then you can move to the section 'Advanced configuration – Events and Outputs – Hardware outputs' and make a right click on this item. After that click on the 'Add New Output'

Once you click on 'Add New Output' new window will appear. Click on add and output will be added right away. Now you can Rename the output, select output on device, which will be controled by this virtual output you just created, set its duration and even test it to ensure that you are picking right output. When everything is set, confirm it by pressing OK. Assign the output to the camera That´s everything you need to set in the 'Milestone Management Application'. Right now you can start 'Milestones Smart Client' which is surveillance window for video monitoring (for security guys). Once you run this application for the first time you will see several sections on the left side (added cameras, created outputs, detected audio devices) but there will be no video preview on the right side of the screen. You can very easily drag selected camera and drop it into any window on the right side (this is settings only for actual login). You can also activate selected output from this client – choose appropriate output (relay) and click on the “Activate” button as shown in the picture below. Finally you can also enable double way audio – you can set microphone for listening-in and also select appropriate speaker to which you want to talk (you have to press and hold button 'Talk'). If you want to create different preview, add cameras permanently into the active area on the right side and add there some special buttons for relay activation or for talking to the speakers then you have to go to the setup mode. Click on the 'Setup' button on the top right corner as shown in the next picture. Everything is based on drag and drop principle. You can move there camera, button for output activation or button which will allow you to talk trough the speaker of the device. Finally you have to click on the 'Setup' button again. You will move back to the live preview and you can monitor selected cameras, you will see extra added buttons in the preview and also windows layout will be modified based on your settings. Buttons for talk to speaker and for output activation will be visible, when you will stay on the camera window with cursor of your mouse. Press the button Output to acivate a switch at Helios IP intercom.

Output Mapping

Model	Output 1	Output 2	Output 3	Output 4	Output 5
2N® Helios IP Verso	LED Secured	Relay 1	Output 1	None	None
2N® Helios IP Vario	Relay 1	Relay 2	Relay 1 (Card Reader)	Relay 2 (Card Reader)	LED1 (Card Reader)
2N® Helios IP Force	Relay 1	Output 1	LED Ringing	LED In Call	LED Door
2N® Helios IP Video Kit	Relay 1	LED 1	LED 2	LED 3	Output 1
2N® SIP Audio Converter	Relay 1	None	None	None	No

As an example an alarm raised when Helios digital input is activated will be configured. Alarm will be raised when a Hardware Input Event is registered in Milestone VMS. To add the Hardware Input Event follow instructions bellow:

Event will be generated when signal on input 1 raises. Input 1 in Milestone VMS corresponds with the Helios digital input 1. Select desired input an click OK. Click Save button to apply the changes. Now new alarm definition is to be created. Select Create New Alarm Definition as shown above. Define the event which will trigger this alarm. Select the event which was configured in the previous step. Click Save again to apply the changes. When the Helios input is activated, the alarm event will appear in the Milestone XProtect Smart Client.

Required licenses

• Enhanced Video for RTSP streaming and ONVIF

Version 2014

Tested Functions

Version VMS	Version Helios IP	Scan device	Video from HIP	Audio from HIP	Audio to HIP	Switch control	Eventrs from HIP
Milestone XProtect Enterprise 2014 ford focus se user manual. Some of the safety features available with Ford Focus are Front-impact airbags, occupancy sensors, sideimpact bars, front seatbelt pretensioners, sideimpact airbags, ABS etc. The first generation Focus has won over 60 awards including 13?Car of the Year? 8.6a	2N Helios IP 2.10.0.19.3

2N Helios IP Settings

As a very first step you have to do a configuration under the section Onvif. Please keep in mind that the Onvif protocol is licensed, for full functionality you need to have a 'enhanced video' license for 2N Helios IP unit. Enable at least one ONVIF user with the Administrator access level in menu Services / Onvif.

Smart Client Applications

Enable parameter RTSP Server Enabled in menu Services / Streaming.

Tested Features

On the side of Milestone server do right click on Hardware Devices and and click on Add New Hardware Device.

In next step you can choose if you want to add device manually or if you want to scan your local network for ONVIF ready devices. We choosed automatic scan as it is much eaiser. Here you can choose if you want to scan local network, or you can define IP range which you want to scan and press next. Then you will see window where you can choose particular manufacturer or it is ok to leave it as it is 'All manufacturers' and click on next. Once the scan will be finished, you will see devices in your network. Find your device and enter valid credentials (we used ONVIF/ONVIF for this FAQ) and press Go. After you will enter valid credentials, it will be possible to pick tde device and click on next. Then you will get a message that device was sucesfully added. Now you will see the device in list 'Hardware Device Summary'. Here you can edit its name simply by clicking in filed 'Hardware device name'. Now the device will appear in tree menu of 'Hardware Devices'. If you open it, you will see peripheries of the device. If you click on of them, you can change its name. By right clicking on any of them, you can open its Properties and adjust some settings. In pictures below, you can see how to adjust camera settings right from the XProtect Application.

Enable Setup and configure Overlay Buttons / Application / Talk to speaker(s). Press the button Talk to speaker(s) to stream audio from microphone to the speaker.

Onida black beauty microwave oven user manual. Once you have successfully added new hardware devices into the Milestone VMS system (camera, microphone and speaker) which was described in the previous part of this FAQ then you can move to the section 'Advanced configuration – Events and Outputs – Hardware outputs' and make a right click on this item. After that click on the 'Add New Output'.

Once you click on 'Add New Output' new window will appear. Click on add and output will be added right away. Now you can Rename the output, select output on device, which will be controled by this virtual output you just created, set its duration and even test it to ensure that you are picking right output. When everything is set, confirm it by pressing OK. Now you have to tie the output with camera of the device, otherwise you won't be able to display it in Smart Client. In firts point do a right click on 'Camera' and choose 'Properties'. Then is second point choose 'Output'. Now you can pick desired device and see outputs added to this device before. Choose desired output in third point and then move it by clicking on arrow in fourth point. That´s everything you need to set in the 'Milestone Management Application'. Right now you can start 'Milestones Smart Client' which is surveillance window for video monitoring (for security guys). Once you run this application for the first time you will see several sections on the left side (added cameras, created outputs, detected audio devices) but there will be no video preview on the right side of the screen. You can very easily drag selected camera and drop it into any window on the right side (this is settings only for actual login). You can also activate selected output from this client – choose appropriate output (relay) and click on the “Activate” button as shown in the picture below. Finally you can also enable double way audio – you can set microphone for listening-in and also select appropriate speaker to which you want to talk (you have to press and hold button 'Talk').

If you want to create different preview, add cameras permanently into the active area on the right side and add there some special buttons for relay activation or for talking to the speakers then you have to go to the setup mode. Click on the 'Setup' button on the top right corner as shown in the next picture. Everything is based on drag and drop principle. You can move there camera, button for output activation or button which will allow you to talk trough the speaker of the device.

Finally you have to click on the 'Setup' button again. You will move back to the live preview and you can monitor selected cameras, you will see extra added buttons in the preview and also windows layout will be modified based on your settings. Buttons for talk to speaker and for output activation will be visible, when you will stay on the camera window with cursor of your mouse.

Required licenses

• Enhanced Video for RTSP streaming and ONVIF

Used Symbols

- Compatible
